1 channel optical transceiver-ZMUX-08S-1

Zmux-08s-1 is a miniaturized 1-way telephone optical terminal, which is mainly used for telephone, audio, data, image and other multi service access. Through multiplexing to 1-way optical signal transmission, the multi service signal point-to-point communication function is realized.
Zmux-08s-1 adopts modular design, which can expand up to 8 general service slots and 1 special Ethernet slot. It can completely assemble equipment according to the service and quantity required by customers, especially suitable for small capacity stations.
Zmux-08s-1 is a small box case, which can be placed on the desktop or installed in a 19 inch cabinet. High cost performance, can effectively support the current business needs of users, reduce the cost of system investment, and provide customers with a cost-effective solution.

Functional characteristics

1. Simple installation and maintenance: small box case, 1U high, can be installed on the desktop, optional rack lug, installed in 19 inch cabinet, RJ45 crystal head design.
2. Extensibility design: modular structure, with 8 general module slots and 1 Ethernet special slot, which can mix all kinds of interfaces and functional modules, meet the current application needs and future expansion needs to replace or add corresponding modules, so as to achieve an economic and flexible solution.
3. Safe and flexible design: one sub card module corresponds to one channel of service port, each module works independently, and the fault does not affect each other. The sub card module supports mixed insertion, and can be completely assembled according to the customer's business requirements.
4. There are many types of services: FXO / FXS, 2 / 4-wire E & M, asynchronous / synchronous RS232, asynchronous / synchronous RS422, RS485, 10 / 100Base-T, E1, v.21/v.22, V.24, V.34, switching quantity, can bus, magnet telephone, hotline, V.35, G.703, 64K in the same direction, etc.
5. Optical port: double fiber or single fiber is optional.
6. Transmission distance: optional 40km / 60km / 80km / 100km.
7. Power supply: optional AC220V or dc-48v or AC220V + dc-48v.

Networking application
